Incinerator for Animal Crematory Pig Farm Model A1200
*** 3 sets Burners*** Good for animals or big pets*** Double Combustion chamber*** stainless steel chimney*** Italy made oil burners*** 1200Liters(1.2m3) big chamber
Model
A1200
Burning Rate
Typical 50 kgs/hour
Feed Capacity
Average 100 kgs/feeding
Main Combustion Chamber
1200 Liters
Secondary Combustion Chamber
500 Liters
Mix Combustion Chamber
Yes
Smoke Filter Chamber
Yes(Dry Scrubber)
Feed Mode
Manual
Voltage
220V/380V
Fuel Type
Diesel Oil
Burner
Italy Original
Oil Consumption (Diesel Oil)
Average 34.4 kg/hour
Gas Consumption (Natural Gas)
***
Internal Dimensions
130x100x90cm (primary chamber)
External Dimensions
220x180x360cm (without chimney)
Temperature Monitor
Yes
Oil Tank Capacity(if oil fuel)
500 Liters
Door Opening
55 x 80cm
Chimney Length
10.0 Meters
Chimney Type
Stainless Steel
Equipment Gross Weight
7500 kgs
Operation Technical Specifications
Main Chamber Temperature
800℃–-1000℃
Secondary Chamber Temperature
1000℃-1200℃
Residency Time
2.0 Sec.
Burning Efficiency
>98%
Waste Lower Calorific Power
3000Kcal |
Model |
|||
A1200 |
Internal Dimensions |
|||
130x100x90 cm |
Suit for Animal |
Cat – yes |
Dog – yes |
Pig – little |
Cow – no |
Main Product List |
|||
Primary Combustion Chamber |
||||
Secondary Combustion Chamber |
||||
Mix-Combustion Chamber |
||||
Smoke Filter Chamber(Dry Scrubber) |
||||
Incinerator Control Case |
||||
Chimney:10.0Meters *(update to Stainless Steel, free price ) |
||||
Italy oil burner: 03 sets |
Oil Tank: 500Liters
