Design
YD-150
Burning Price
Average 150 kgs/hour
Feed Capability
Standard 300 kgs/feeding
Key Burning Chamber
1500 Liters
Additional Burning Chamber
500 Litres
Mix Burning Chamber
Yes
Smoke Filter Chamber
Damp Scrubber System( 3 Area Type)
Feed Setting
Manual
Voltage
380V
Power
9.0 Kw
Gas Kind
Diesel Oil/ All-natural Gas/LPG
Burner
Italy Original
Oil Consumption (Diesel Oil)
Average 24 kg/hour
Gas Intake (Gas)
***
Inner Dimensions
150 x 100 x 96cm (primary chamber)
Exterior Dimensions
240 x 170 x 380cm( without chimney/wet scrubber)
Temperature Monitor
Yes
Oil Tank Capacity( if Petroleum fuel)
300 Liters
Door Opening
59 x 81cm
Chimney Length
10.0 Meters
Chimney Kind
Stainless Steel
Equipment Gross Weight
11000 kgs
Procedure Technical Specs
Main Chamber Temperature Level
800 ℃–– -1000 ℃
Second Chamber Temperature Level
1000 ℃ -1200 ℃
Residency Time
2.0 Sec.
Burning Efficiency
> 98 percent
Waste Lower Calorific Power
